CH802FD21 Sofima Hydraulic Filter Element

Description:

Sofima Hydraulic Filter Element CH802FD21 is a high-precision filter element for hydraulic oil and lubricating oil filtration. It uses high-quality glass fiber and metal mesh pleated filter materials.

Model: CH802FD21

Filtration Accuracy: 10um

Brand: HYFILTER

Material: Glass fibre

Outer diameter: 77.97mm

High: 209.80mm

Share With:

Sofima Hydraulic filter element CH802FD21 is a high-Precision filter element for hydraulic oil and lubricating oil filtration. It uses high-quality glass fiber and metal mesh pleated filter materials. The flat and uniform folding process can ensure that the filter element is not easy to be blocked during use. , and can make the service life of the filter element longer. Huayuan Environmental Protection has been focusing on the production and development of Hydraulic oil filter elements and Air Compressor Filter elements for many years. The filter elements have undergone strict technical testing before leaving the factory.

Technical data

Model: CH802FD21

Outer diameter: 77.97mm

Inner diameter: 42.92mm

Length: 209.80mm

Filtration precision: 10 microns

Max Operating Pressure:3045 PSID Collapse

Max Temp: 248 Degress F

Manufacturer: Xinxiang Huayuan Environmental Protection Technology Co., Ltd.
