The replacement Parker FC7007.Q005.BK hydraulic oil filter element has stable in
Model: FC7007.Q005.BK
Filtration Accuracy: 5μm
Brand: HYFILTRATE
Material: fiberglass
Outer diameter: 78mm
High: 330mm
The replacement Parker FC7007.Q005.BK Hydraulic oil filter element has stable interception efficiency and dirt holding capacity, continuously intercepting small solid pollutants and avoiding impurities from flowing back and depositing inside the oil tank. The dense and uniform wrinkled layout evenly distributes fluid load and effectively controls the operating pressure difference. The metal casing strengthens the structural strength of the filter layer and reduces the risk of damage caused by high-pressure impact. The end cover is equipped with a lifting structure, which facilitates on-site disassembly and maintenance. Fluororubber seals can withstand high and low temperature changes, slow down aging and leakage, and are suitable for long-term uninterrupted cyclic filtration conditions.
Wind power transmission system: gearbox lubricating oil, hydraulic actuator purification unit
Precision injection molding equipment: servo hydraulic oil circuit return oil filtration device
Large machine tool unit: multi-channel hydraulic oil supply system medium protection unit
Port light lifting equipment: hydraulic circuit end oil purification device
Other scenarios include servo hydraulic power stations, industrial robot hydraulic systems
1) Same shell universal filter element (universal external dimensions): FC7007.Q010.BK, FC7007.Q003.BK
Tip: There are differences in filtering accuracy and they cannot be interchanged arbitrarily.
2) Alternative model: TZX2-330 × 5, with consistent external dimensions, structural parameters, and filtration indicators, available for selection reference.
3) Important reminder for replacement selection: The outer diameter, total length, and positioning inner hole size must match; Fiberglass filter material cannot be washed and regenerated; Regularly monitor changes in pressure differential and promptly identify internal sources of pollution in the system.
Packaging: Internally packaged in plastic bags, externally packaged in cardboard boxes
Transportation: pallets or wooden boxes
Specific requirements can be based on the customer's specific needs
FC7007.Q005.BK、FC7007.Q010.BK、FC7007.Q003.BK、FC7007.Q016.BK、FC7007.Q020.BK
FC7006.Q005.BK、FC7009.Q005.BK、FC7007.Q005.VK、FC7007.Q005.BS、FC7007.Q005.BP
FC7007.Q005.BA、FC7007.Q005.LK、FC7007.F005.BK、FC7007.Q005.BX、FC7007.Q005.SK
Replace Parker FC7007.Q005.BK hydraulic oil filter element
Product type: Hydraulic system low-pressure return oil precision filter element
Filter material configuration: multi-layer asymmetric gradient glass fiber medium, fluid flow direction from outside to inside
Filtering accuracy: 5 μ m, capturing fine abrasion powder, colloidal suspension, and tiny hard particles
Allowable maximum pressure difference: 21 bar, able to withstand pressure fluctuation impact of reflux system
Sealing material: Fluororubber sealing ring, suitable for various hydraulic and synthetic media
Working temperature range: -30 ℃ to+120 ℃
Supporting structure: Continuous punched steel inner and outer casing, restraining wrinkling deformation and resisting fluid disturbance
Suitable fluids: mineral hydraulic oil, circulating lubricating oil, water ethylene glycol flame retardant medium
1. High quality filtration materials: We strictly select high-quality materials such as glass fiber and stainless steel metal mesh to ensure filtration efficiency and long service life.
2. Compliant with industry standards: The product meets user needs, is compatible with most hydraulic systems, and has excellent quality.
3. Customizable: We can provide customized solutions based on your various models and brands, as well as replacement requirements under different working conditions.
4. Cost effectiveness: The factory directly supplies, crosses intermediaries, and reduces procurement costs while maintaining excellent quality.
