Oil system, jacking oil system, and oil regulating security system in generating units is important to ensure the safe and stable operation of the system unit. The reliability of these systems work and cleanliness turbine oil, anti-oil, fuel oil and other media have a close relationship.

In order to ensure the safe operation of the system, improve the service life and reliability of the systems require different types of filters and filtration equipment for oil purification media.

Turbine generator oil system is the set of processes (steam turbines, gas turbines and turbine generator) to run in an integral unit, the main role is to support bearings, thrust bearings and winch to provide lubrication. The filter is an important part of the lubricating oil system, for ensuring the cleanliness of the oil plays a key role.

In turbine oil systems, filters can be divided into the tank filter and line filter based on the location of the installation; according to product structure, it can be divided into a single joint filter and double-filter. Filters are mostly online used. The installation location and structure according to the site need to be selected. Moreover,it can also use the filtering devices Processing turbine oil purification fuel tank outer loop bypass. To remove moisture and deposition of particulate impurities in the fuel tank, to further improve the oil cleanliness level.

SIMPLEX FILTERS

Simplex filters mainly used to filter the hydraulic oil, Lubricating oil mixed with mechanical impurities, and Oil chemical reaction product, to prevent contamination of the hydraulic components wear, Pressing pollution, pollution clogging, and prevent deterioration of the medium.There are (low pressure) line filter, (MV) line filter, (high pressure) line filter, Suction Filter box,The box Suction Filter、self-styled suction filter, Back to the oil filter on the tank , the self-styled back to the oil filter, high-pressure plate filter, etc., which will help to choose a variety of ways.

Key performance indicators

design pressure：1.0、1.6、2.5、4.0、6.3、10.0、16.0......MPa

Operating temperature:-20~80℃

Filtration accuracy:4、6、10、14、20、25、30、40......µm(c)

Filter Ratio（β）：50、75、100、200、1000、5000

design pressure：1.0、1.6、2.5、4.0、6.3、10.0、16.0......MPa

Filter structural strength：700KPa

Pressure sender：0.05、0.08、0.1、0.15、0.2、0.25、0.30、0.35MPa

Bypass valve opening pressure:0.10、0.15、0.20、0.25、0.30、0.35、0.5MPa

Flow range：0~6000L/min

DOUBLE FILTER

Duplex filter, also known as double-switch filter which consists of two filter switching valves, at work, it switches the valve filter through work, with good sealing, flow capacity, easy operation and many other advantages, applications a wide range. The filter is suitable for low pressure pipeline uninterrupted work of hydraulic lubrication system or in the return line for filtering hydraulic oil, mainly used to filter the hydraulic oil, Lubricating oil mixed with mechanical impurities, and Oil chemical reaction product, to prevent contamination of the hydraulic components wear, Pressing pollution, pollution clogging, and prevent deterioration of the medium.There are (low pressure) line filter, (MV) line filter, (high pressure) line filter, Suction Filter box,The box Suction Filter、self-styled suction filter, Back to the oil filter on the tank , the self-styled back to the oil filter, high-pressure plate filter, etc., which will help to choose a variety of ways.

Key performance indicators

design pressure：1.0、1.6、2.5、4.0、6.3、10.0、16.0......MPa

Operating temperature:-20~80℃

Filtration accuracy:4、6、10、14、20、25、30、40......µm(c)

Filter Ratio（β）：50、75、100、200、1000、5000

Filter structural strength：700KPa

Pressure sender：0.05、0.08、0.1、0.15、0.2、0.25、0.30、0.35MPa

Bypass valve opening pressure:0.10、0.15、0.20、0.25、0.30、0.35、0.5MPa

Flow range：0~6000L/min
